PART №1618

Centre-Console Attachment Bracket

REPLACES OEMA2016830035
ABS · Nylon · PETG1 FILECC-BY-SAConsole & storage
SummaryREF 1618
PART
Centre-Console Attachment Bracket
OEM
A2016830035
FITS
190 Series W201
PartREV 2026

Loading 3D viewer...

Ref 16181 STL filePrints without supports
Field photographs
3 PLATES
Plate 1 of 3
PLATE 01 / 03No caption recorded
Files & dimensions
MAN-1618
  • [01]A201_683_00_35.stl.STL
  • [02]Bounding box54.403 × 35.850 × 22.000 mm
  • [03]Volume7,031.403 mm³
Field notes
BY THXANDBYE

Replacement angle bracket connecting the centre-console panel to the transmission-tunnel covering on earlier cars. The creator copied the broken original, identifies EPC position 44, and states that the original threaded insert and screw are reused. Confirm early-model console geometry, use tough cabin-heat-resistant material, and tighten only enough to retain the trim without cracking the bracket.
