Centre-Console Panel Pin

ABS · Nylon · PETG1 FILECC-BYConsole & storage
SummaryREF 1586
PART
Centre-Console Panel Pin
OEM
FITS
W123 Series W123 / S123 / C123
PartREV 2026

Loading 3D viewer...

Ref 15861 STL filePrints without supports
Field photographs
2 PLATES
Plate 1 of 2
PLATE 01 / 02No caption recorded
Files & dimensions
MAN-1586
  • [01]ConsolePin300D.stl.STL
  • [02]Bounding box49.731 × 28.198 × 26.864 mm
  • [03]Volume4,485.09 mm³
Field notes
BY FORWARD PHONE (FORWARDOBI)

Replacement plastic locating pin for the wooden switch panel in the centre console, demonstrated on 240D and 300D cars. The creator provides a central hole for an optional cut-down steel nail bonded with adhesive to reinforce the shaft. Keep metal reinforcement fully encapsulated and clear of wiring, use heat-resistant material, and confirm the panel is retained without stressing the veneer or switches.
