Merc 3D Parts
PART №1643

Console Storage Tray

ABS · Nylon · PETGMULTI-PART3 FILESCC-BYConsole & storage
SummaryREF 1643
PART
Console Storage Tray
OEM
FITS
G-Class W463
PartREV 2026

Loading 3D viewer...

Ref 16433 STL filesPrints without supports
Field photographs
3 PLATES
Plate 1 of 3
PLATE 01 / 03No caption recorded
Files & dimensions
MAN-1643
  • [01]Ablagefach.stl.STL
  • [02]Ablagefach_voll.stl.STL
  • [03]Ablagefach_voll.stp.STL
Field notes
BY EBO LOMPEDO (EBOLOMPEDO)

Storage tray for 1990s vehicles, shown fitted in the dashboard opening beside the audio unit. The author supplies divided and undivided STL variants plus the undivided STEP source. No material or print settings are stated. Compare the opening and adjacent switch/audio layout before printing, use material appropriate for cabin heat, deburr the retaining features and confirm the tray and stored objects cannot interfere with controls or become loose under braking.
