PART №1844
Modular Console Cupholder and Storage System
REPLACES OEMA2056800691
ABS · NylonMULTI-PART24 FILESCC-BY-NC-SAConsole & storage
- PART
- Modular Console Cupholder and Storage System
- OEM
- A2056800691
- FITS
- C-Class W205 / S205 / C205 / A205, E-Class W213 / S213 / C238 / A238, Vito / Viano / V-Class W447
Loading 3D viewer...
Ref 184424 STL filesPrints without supports
Field photographs
6 PLATES
PLATE 01 / 06No caption recorded
Files & dimensions
MAN-1844- [01]Base Unit Front-Cover - Cover.stlBase Unit Front-Cover - Cover.stl.STL
- [02]Base Unit-Back - Frame.stlBase Unit-Back - Frame.stl.STL
- [03]Base Unit-Back - Gridfinity-Baseplate.stlBase Unit-Back - Gridfinity-Baseplate.stl.STL
- [04]Base Unit-Back - Socket-Frame-Connector.stlBase Unit-Back - Socket-Frame-Connector.stl.STL
- [05]Base Unit-Back - Socket.stlBase Unit-Back - Socket.stl.STL
- [06]Base Unit-Back - Storage-Box-Back.stlBase Unit-Back - Storage-Box-Back.stl.STL
- [07]Base Unit-Back - Storage-Box-Left.stlBase Unit-Back - Storage-Box-Left.stl.STL
- [08]Base Unit-Back - Storage-Box-Right.stlBase Unit-Back - Storage-Box-Right.stl.STL
- [09]Base Unit-Front - Base-Cover-Connector.stlBase Unit-Front - Base-Cover-Connector.stl.STL
- [10]Base Unit-Front - Frame.stlBase Unit-Front - Frame.stl.STL
- [11]Base Unit-Front - Gridfinity-Baseplate.stlBase Unit-Front - Gridfinity-Baseplate.stl.STL
- [12]Base Unit-Front - Socket.stlBase Unit-Front - Socket.stl.STL
- [13]Cupholder - Base.stlCupholder - Base.stl.STL
- [14]Cupholder - Cupholder.stlCupholder - Cupholder.stl.STL
- [15]Cupholder-Clip - Clip.stlCupholder-Clip - Clip.stl.STL
- [16]Storage Box-Back-Right - Box.stlStorage Box-Back-Right - Box.stl.STL
- [17]Storage Box-Back-Right - Lid.stlStorage Box-Back-Right - Lid.stl.STL
- [18]Storage Box-Big - Box.stlStorage Box-Big - Box.stl.STL
- [19]Storage Box-Big - Partition-Across.stlStorage Box-Big - Partition-Across.stl.STL
- [20]Storage Box-Big - Partition-Along.stlStorage Box-Big - Partition-Along.stl.STL
- [21]Storage Box-Front-Left - Box.stlStorage Box-Front-Left - Box.stl.STL
- [22]Storage Box-Front-Left - Partition.stlStorage Box-Front-Left - Partition.stl.STL
- [23]Storage Box-Long - Box.stlStorage Box-Long - Box.stl.STL
- [24]Storage Box-Long - Partition.stlStorage Box-Long - Partition.stl.STL
Field notes
BY CNOWMulti-part Gridfinity-based replacement for the center-console cupholder and storage unit, explicitly stated by the creator to fit V-Class/Vito, C-Class, E-Class sedan/estate/coupé/cabriolet applications sharing the original insert. It reuses the original double-torsion spring, adds supported cupholder clips, and uses 6×2 mm magnets. Preserve spring orientation, secure every magnet, verify each module locks in place, and keep all contents and moving parts clear of controls. The creator identifies the exact replaced cupholder unit as A2056800691, corroborated by the official Mercedes-Benz genuine-parts listing.
