PART №1581
Seat-Cushion Upholstery Clip
ABS · Nylon · PETG1 FILECC-BYSeats & restraints
- PART
- Seat-Cushion Upholstery Clip
- OEM
- —
- FITS
- S-Class W140 / C140, SL R129, W123 Series W123 / S123 / C123
Loading 3D viewer...
Ref 15811 STL filePrints without supports
Field photographs
2 PLATES
PLATE 01 / 02No caption recorded
Files & dimensions
MAN-1581- [01]Seat_Cushion_Cover_Clip.STLSeat_Cushion_Cover_Clip.STL.STL
- [02]Bounding box21.792 × 9.261 × 6.000 mm
- [03]Volume541.323 mm³
Field notes
BY (PREADOR)Replacement clip joining seat upholstery to the internal metal rod. The creator explicitly states use on W123, W140 and R129 seats and recommends ABS rather than PLA. Compare the original clip and seat construction, use a tough heat-resistant material, round and clean every contact edge and confirm the upholstery is retained without cutting the fabric or affecting seat adjustment. Source-stated numbers 1239884078 and 1409883778 were not assigned because an independent exact EPC child-component mapping was not recoverable in this run.
